Integral automobile swicth/integral automobile metal pushbutton switch

  • Integral automobile swicth/integral automobile metal pushbutton switch
  • Integral automobile swicth/integral automobile metal pushbutton switch
  • Integral automobile swicth/integral automobile metal pushbutton switch
  • Integral automobile swicth/integral automobile metal pushbutton switch
  • Integral automobile swicth/integral automobile metal pushbutton switch
Model No.︰MPB16
Brand Name︰TS
Country of Origin︰China
Unit Price︰-
Minimum Order︰1000 pc
Share on:

 Total 43 Related Items
Prev34567Next

Product Description
◆ Mounting hole:Φ16mm ◆Shape of top:Round/High/Flat shape ◆Lamp shade:PC
◆ Voltage class:250V ◆Buttom accesories:Wiring inser(2.8x0.4mm) ◆Surface disposal:SUS/Brass with nickel/Black coated
◆Rated current:3A ◆Dielectric Strength:2000VAC ◆Base:PA66
◆Contact resistance:≤50mΩ ◆Operation Temperature:-20℃~+85℃ ◆Kind of lamp:LED
◆ Insulation resistance: ≤1000mΩ ◆Thickness of panel:~ 10mm ◆Rated voltage for lamp:3V/6V/12V/24V/36V/110V/220V
◆ Material of frame: SUS/Brass  ◆Nut Length:~ 14Nm  ◆Rated current for lamp: could select
◆ Protection level:IP40,IP65, IP67,IK10 ◆Function:OFF-ON,OFF-(ON),Reset,Lock,No Lock etc ◆Color of push-button:R/B/G/Y/W
◆ Brand manufacturer: TOPSHALL ◆Operating life:50000H
◆For more products and details,pls click the link:http://www.topshallelectronic.com/products.php?bid=96&fid=16
Payment Terms︰TT,Western union,paypal etc
